Compact Range

LU-GY1C Pneumatic Paste & Liquid Filling Machine

Enquire now Arrange a Demonstration Call Now
Ready to discuss LU-GY1C Pneumatic Paste & Liquid Filling Machine? Tell us your product, pack size and output target and we will help you shortlist the right configuration.
Call 01494 623015 Get a quote Browse categories

Machine overview

Key information to help you specify the right configuration.

LU-GY1C Pneumatic Paste & Liquid Filling Machine preview
The LU-GY1C filling machine is designed for efficient, semi-automatic filling of liquids and pastes such as water, lotion, honey, and cream. Equipped with a 2-meter conveyor belt, it integrates seamlessly with automatic capping and labeling machines, making it ideal for streamlined production lines in cosmetics, food, pharmaceuticals, and daily chemical industries.
Throughput
10–20 bottles/min
Throughput depends on product, format and operator workflow.
Format range
5–100 ml / 10–300 ml / 50–500 ml / 100–1000 ml / 500–3000 ml / 1000–5000 ml (optional)
Configured to your bottle, closure and fill volume.
Utilities
220V / 110V, 50/60Hz
Voltage, air and installation requirements confirmed for your site.

Specifications

Reference specification table. Final configuration may vary with options and scope.

ParameterValue
Model LU-GY1C
Power Supply 220V / 110V, 50/60Hz
Power 130 W
Filling Accuracy ≤ ±0.5%
Filling Speed 10–20 bottles/min
Filling Volume Range 5–100 ml / 10–300 ml / 50–500 ml / 100–1000 ml / 500–3000 ml / 1000–5000 ml (optional)
Conveyor Size (L×W) 2000 × 100 mm
Filling Nozzle Diameter Φ10 mm
Required Air Pressure 0.4–0.6 MPa
Air Connector Size OD 8 mm
Air Consumption ≥ 0.1 m³/min
Machine Weight 24 kg (filling machine) + 4 kg (hopper) + 61 kg (conveyor)
Packing Weight 30 kg (filling machine) + 5.5 kg (hopper) + 89 kg (conveyor)
Packing Size 113 × 35 × 30.5 cm (filling machine) / 46.5 × 47 × 52 cm (hopper) / 210 × 62 × 53 cm (conveyor)

CAD / dimensions

CAD/dimensions are provided in a pop‑out viewer.

No CAD/dimensions drawing uploaded yet.

Site requirements

  • Power: 220V / 110V, 50/60Hz
  • Air pressure: 0.4–0.6 MPa
  • Air consumption: ≥ 0.1 m³/min
  • Footprint / size: 2000 × 100 mm
For the most accurate proposal, include: product viscosity/foaming, container size, closure type, and required units per hour.

Quick answers

Clear answers for buyers, engineers and AI-driven search summaries.

What is LU-GY1C Pneumatic Paste & Liquid Filling Machine used for?

The LU-GY1C filling machine is designed for efficient, semi-automatic filling of liquids and pastes such as water, lotion, honey, and cream. Equipped with a 2-meter conveyor belt, it integrates seamlessly with automatic capping and labeling machines, making it ideal for streamlined production lines in cosmetics, food, pharmaceuticals, and daily chemical industries.

What output can LU-GY1C Pneumatic Paste & Liquid Filling Machine achieve?

This page lists output at 10–20 bottles/min. Actual throughput depends on the product, container, fill volume, changeover requirements and overall line setup.

What utilities or site requirements should I plan for?

Power: 220V / 110V, 50/60Hz; Air pressure: 0.4–0.6 MPa; Air consumption: ≥ 0.1 m³/min

Can Lancing UK help match this machine to my product and container?

Yes. Lancing UK can review your product characteristics, bottle or pack format, closure type, required output and site constraints to confirm the right configuration before supply.

Talk to a specialist

We’ll confirm suitability, options, integration, and realistic throughput for your product.

Call: 01494 623015 Arrange a demonstration

Enquire about this machine

Send a message and we’ll respond with configuration options, pricing guidance and lead times.
